| Part Number | DC BreakdownVo ltage(VBR)@100V/s(V) | Tolerance of VBR(V) | Impulse Spark-overVoltage@1KV/μs(V) | Arc Voltage (Va)@1A(V) | Impulse Discharge Current@8/20μs(KA) | Insulation Resistance(GΩ) | @ DC(V) | Capacitance CO 0.5VDC@1MHZ(pF) | Size L*W*H(mm) | 搜索 | |
| BD122-J | 1200 | 700-1450 | ≤1100V(@1.2/50μs 6kV) | ≤60 | 15 | ≥1 | 100 | ≤1.5 | 6*6*16.5 | ||
| BUB801M-02 | 600 | 520-780 | ≤1300V | ~24V | 40KA | ≥1 | 100 | ≤4.0pF | Φ16*7.7 | ||
| BUB801M-06 | 800 | 640-960 | ≤1400 | ?24 | 40 | ≥1 | 100 | ≤4.0 | Φ16x5.6 | ||
| BD122-2 | 1200 | 700-1200 | ≤900V (@1.2/50μs 6kV) | ≥60 | 20KA | ≥1 | 100 | ≤1.5pF | 8.3*9.5*16.5 |
